Responsive Layout in Mobile Client

Post by Paul_Ramcharitar »

I created a display using the Responsive Layout widget. It is made to run in mobile devices using the Profound Ui Mobile client app.

However, when I run it on a Samsung Tablet (Model: SM T285) using the mobile client, all of the content in the responsive layout seems to be condensed to horizontal lines. Please see attached image. If I run it in the chrome browser of the same device, it loads perfectly.

It also loads perfectly on:
- Apple iPad Pro 12.5" using the Profound Ui Mobile client app.
- Samsung Galaxy S7 Edge using the Profound Ui Mobile client app.
- Desktop browsers.

For some reason it is not loading correctly on the Samsung Tablet (Model: SM T285). Please assist.
Attachments
User avatar
matt.denninghoff
Profound Logic Staff Member
Posts: 115
Joined: Wed Feb 10, 2016 3:53 pm
First Name: Matthew
Last Name: Denninghoff
Company Name: Profound Logic Software
State / Province: Ohio
Country: United States
Contact:

Re: Responsive Layout in Mobile Client

Post by matt.denninghoff »

HI. I wrote the responsive widget, and I can't see what's happening here without debugging it. I've seen things get compacted like that when the container that the responsive widget is inside does not have a height that the CSS rules can use.

As a workaround, you could try adding the widget inside another layout widget with a discrete height (specified in pixels) or set the "use viewport" property of the responsive layout to false to see if the container height is the problem.
Paul_Ramcharitar
Profound User
Posts: 91
Joined: Fri Aug 03, 2012 11:07 am
First Name: Paul
Last Name: Ramcharitar
Company Name: Banks DIH
City: Georgetown
Zip / Postal Code: 592
Country: Guyana
Contact:

Re: Responsive Layout in Mobile Client

Post by Paul_Ramcharitar »

Hi. I added the responsive layout in another layout and it is working now.

Thank you for your help.
